SCHUNK PGN-plus-P User Manual

Technical data
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
17
3 Technical data
Connection data
Designation PGN-plus-P
Pressure medium Compressed air, com-
pressed air quality accord-
ing to ISO 8573-1: 7:4:4
Nominal operating pressure [bar] 6
Minimum pressure [bar]
without maintenance of gripping force
with maintenance of gripping force
2.5
4
Maximum pressure [bar]
without maintenance of gripping force
with maintenance of gripping force
8
6.5
Pressure range for air purge [bar] 0.5 – 1
Ambient conditions and operating conditions
Designation PGN-plus-P
Ambient temperature [°C]
min.
max.
+5
+90 / VHT: +130
Protection class IP * 40 / SD: 64
Noise emission [dB(A)] ≤ 70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
More technical data is included in the catalog data sheet.
Whichever is the latest version.
