General
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
7
1.2 Warranty
If the product is used as intended, the warranty is valid for 36
months from the ex-works delivery date under the following
conditions:
• Observe the ambient conditions and operating conditions,
Technical data [
}
17]
• Observe the specified maintenance intervals,
Maintenance [
}
48]
Parts touching the workpiece and wear parts are not included in
the warranty.
Designation PGN-plus-P
40 50-160 200-240 300-380
Warranty duration
[months]
36 36 36 36
or maximum cycles [mil.] 40 30 20 10
* One cycle consists of a complete gripping process: "Open
gripper" (release workpiece) and "Close gripper" (grip workpiece).
1.3 Scope of delivery
The scope of delivery includes
• 2-Finger Parallel Gripper PGN-plus-P in the version ordered
• Accessory pack
Content of the accessory pack:
• 2x centering sleeve for gripper fastening
• 4x centering sleeve for finger fastening
• 2 x O-ring for hose-free direct connection
ID.-No. of the accessory pack
Size ID number
PGN-plus-P PGN-plus-P V/HT
PGN-plus-P 40 5518410 395518410
PGN-plus-P 50 5512043 395512043
PGN-plus-P 64 5512044 395512044
PGN-plus-P 80 5512045 395512045
PGN-plus-P 100 5512046 395512046
PGN-plus-P 125 5512047 395512047
PGN-plus-P 160 5512048 395512048
PGN-plus-P 200 5512049 395512049
PGN-plus-P 240 5513858 395513858
PGN-plus-P 300 5512050 395512050
PGN-plus-P 380 5515137 395515137
