Maintenance
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
55
7.6 Tightening torques
Position of the item numbers: Assembly drawing [
}
56]
PGN-plus-P 40-240: Tightening torque for screws - details in Nm
Size Item 40 Item 41
PGN-plus-P 40 1.2 0.27
PGN-plus-P 50 1.2 1.2
PGN-plus-P 64 6.1 1.2
PGN-plus-P 80 10 3.1
PGN-plus-P 100 15 3.1
PGN-plus-P 125 25 3.1
PGN-plus-P 160 49 2.2
PGN-plus-P 200 65.5 4.3
PGN-plus-P 240 85 4.3
PGN-plus-P 300-380 (without GKS): Tightening torque for screws - details in Nm
Size Item 40 Item45 Item 41 Item 46
PGN-plus-P 300 -1/-2 120 – 6 –
PGN-plus-P 300 AS – 150 – 25
PGN-plus-P 300 IS 120 – – 25
PGN-plus-P 380 -1/-2 200 – 10 –
PGN-plus-P 380 AS – 290 – 50
PGN-plus-P 380 IS 200 – – 50
