Design and description
18
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
4 Design and description
4.1 Design
2-Finger Parallel Gripper
1 Air purge connection
2 Base jaw
3 Compressed air main connection
4 Groove for magnetic switch
5 Housing
4.2 Description
Universal 2-finger parallel gripper with large gripping force and
high maximum moments thanks to multi-tooth guidance.
