SCHUNK PGN-plus-P User Manual

Maintenance
52
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
Ø Insert base jaws (3) into the housing (11).
IMPORTANT!Observe installation position of the base jaws (3)
in the housing (11).
Ø Insert wedge hook (1) into the housing (11).
Ø Insert spring (10) and spacer (4) into the housing (11).
Ø Insert cylinder piston (5) into the housing (11) and align it
precisely. Tighten the screw (8) and secure with medium-
strength threadlocker.
Tightening torque: Tightening torques [
}
55]
Ø Place cylinder pistons (5) on the assembly device (13), slide
towards the housing and tighten screw (8). Secure the screw
with medium-strength threadlocker.
Tightening torque: Tightening torques [
}
55]
Ø Insert flat gasket (7).
Ø Fasten the cover (6) with the screws.
Tightening torque: Tightening torques [
}
55]
Ø Variant Dust-tight (SD): Reassemble dust cover in reverse
order, Remove dust cover [
}
54] .
Ø Fasten the cover (12) with the screws.
Ø Mount product onto the system/machine.
Ø Connect all compressed air lines.
