Assembly
44
12.00 | SWS | Assembly and Operating Manual | en | 389456
Ø Insert dowel pins(6) on the cover plate/SWK into the bores on
the adapter plate.
Ø Apply screw lock to screws(8).
Ø Secure SWK(7) to adapter plate(3) with screws(8).
✓ Observe the tightening torque for the mounting screws.
Item Mounting SWK020 SWK021 SWK041 SWK060
5 Alignment pin Ø4 x 14 Ø6 x 20
8 Mounting screw
according to
standard
M4x30 M4x35 M5x40
DIN EN
ISO 4762
M6 x 40,
DIN EN
ISO 10642
DIN EN ISO 10642
Strength class 10.9 8.8 10.9
Max. tightening
torque [Nm]
1.13 5.08 6.78
Threadlocker Loctite ® 222 Loctite ®
242
