Monitor Overview 9
SCOTT SAFETY 087-0059 REV B
Figure 1 shows the major parts of the monitor.
Figure 1 Major Parts of the Monitor
Table 7 lists the major parts of the monitor.
Table 7 Major Parts of the Monitor
NO. ITEM NO. ITEM
1 Compliance LED (Green) 5 Buzzer
2 Alarm LED (Red) 6 IR Link
3 LCD 7 Alligator Clip
4 Operation Button (2) 6 Sensor Cover
