Default Settings Table 9 and Table 10 provides the default settings of the monitor.
The alarm setpoints and the firmware settings can be configured by the user via the
PGD Application. Refer to the Portable Gas Detection (PGD) Application User Guide
(087-0061).
Table 9 Factory Default Alarm Setpoint
SENSOR TYPES RANGE TWA STEL LOW HIGH
GAS TYPE AND
VALUE FOR
CAL
O
2
0 to 30% N/A N/A 19.5% 23.5% zero air
H
2
S (Standard) 0 to 500 ppm 10 ppm 15 ppm 10 ppm 15 ppm 25 ppm H
2
S
H
2
S
(High Resolution)
0 to 100 ppm 1 ppm 5 ppm 1 ppm 5 ppm 25 ppm H
2
S
CO (Standard) 0 to 1000 ppm 35 ppm 200 ppm 35 ppm 200 ppm 50 ppm CO
CO
(Hydrogen Resistant)
0 to 2000 ppm 35 ppm 200 ppm 35 ppm 200 ppm 50 ppm CO
HCN 0 to 100 ppm 10 ppm 4.7 ppm 4.7 ppm 10 ppm 10 ppm HCN
O
3
0 to 3 ppm 0.1 ppm 0.1 ppm 0.1ppm 0.5 ppm 2 ppm Cl
2
NO 0 to 350 ppm 25 ppm N/A 10 ppm 25 ppm 25 ppm NO
NO
2
0 to 100 ppm 3 ppm 5 ppm 2.5 ppm 5 ppm 5 ppm NO
2
PH
3
0 to 20 ppm 0.3 ppm 1 ppm 0.3 ppm 1 ppm 1 ppm PH
3
SO
2
0 to 150 ppm 2 ppm 5 ppm 2 ppm 5 ppm 9 ppm SO
2
NH
3
0 to 300 ppm 25 ppm 35 ppm 25 ppm 50 ppm 50 ppm NH
3
Cl
2
0 to 50 ppm 0.5 ppm 1 ppm 0.5 ppm 1 ppm 2 ppm Cl
2
ClO
2
0 to 5ppm 0.1 ppm 0.3 ppm 0.1 ppm 0.3 ppm 2 ppm Cl
2
LEL CH
4
0 to 100% LEL N/A N/A 10% LEL 20% LEL 32% LEL
Table 10 Firmware Default Settings
OPTION RANGE FACTORY DEFAULT
Backlight Duration 0 to 5 minutes 5 seconds
Calibration Period 1 to 365 days 1 day
Compliance LED 0 to 4 minutes 60 seconds
Silent Alarm 0 to 60 seconds off
On timer 0 to 9 seconds 3 seconds
Off timer 0 to 9 seconds 5 seconds
Button hold timer (Test) 3 to 9 seconds 3 seconds
Confidence beep On/Off Off
Auto Zero Calibration on
Start-up
On/Off Off
Enable Latching Alarms On/Off Off
Low Battery Alarm 5% to 30% 20%
