Maintenance 39
SCOTT SAFETY 087-0065 REV B
Figure 19 Lithium Battery Access
3 Lift and firmly pull the sensor cover apart. Do not pull apart at an angle or by
twisting.
4 Refer to Replacing Sensors Section to remove the sensor before replacing battery.
5 Replace with the new battery.
Only the Tyco approved batteries are allowed to be replaced in the monitor. Refer to
the battery information in Table 17.
Table 17 Acceptable Battery Information
TYCO PN PART NUMBER MANUFACTURER
8001860 ER14335 EVE ENERGY CO., LTD
8003692 ER14335 OmniCel Batteries
