Protégé Portable Gas Monitor
Instruction Manual
19 of 61
P/N 087-0038 Rev. J 02/10
3.2. Protégé Software
The Protégé comes with a CDROM that includes Scott Monitors proprietary Gas Monitor software
application that enables users to modify the Protégé’s settings and access the data log.
The Gas Monitor application requires the installation of Sun Microsystems® JAVA runtime
application. If not previously installed on the PC, JAVA runtime can be installed on the PC after
installation of the Gas Monitor Software.
PC System Requirements:
• Operating Systems: Windows XP or Windows Vista
• JAVA Version 5 or greater
• USB port
3.2.1. Gas Monitor Software Installation
To install the PCI Gas Monitor software, perform the following.
NOTE
DO NOT CONNECT THE PROTÉGÉ CHARGER TO THE PC UNTIL AFTER THE INSTALLATION IS COMPLETE.
NOTE
FOR WINDOWS® VISTA, PERFORM STEP 1 PRIOR TO BEGINNING INSTALLATION. FOR WINDOWS XP PROCEED TO
STEP
2.
1) For Windows Vista users only, navigate to USER ACCOUNTS AND FAMILY SAFETY using
the control panel and proceed to remove USER ACCOUNT CONTROL (UAC) as shown in
Figure 3-2. The checkbox must be unchecked for UAC. Restart the PC as necessary.
