Protégé Portable Gas Monitor
Instruction Manual
57 of 61
P/N 087-0038 Rev. J 02/10
Figure 5-6. Pump Ports and Hoses
4) Connect a piece of the Tygon tubing to the syringe and draw about 3ml of isopropyl alcohol
into the tubing and syringe.
5) Connect the syringe and Tygon tubing to the INLET port.
6) Connect another piece of Tygon tubing to the OUTLET port and run the Tygon tubing to a
catch basin such as a small cup or trashcan.
