If you want to see the attached alarms or enter a message, please refer to the following chapters. If not, push the Enter
Key and go to the chapter Setting up the SD270.
15.2.3 Viewing alarms attached to the Measurement
From the selecting Measurement screen, you are able to view the alarms attached to the Measurement by pressing F2
Key.
15.2.4 Adding a message to the Measurement
From the selecting Measurement screen, you are able to add a message to the Measurement by pressing F3 Key. Then
the following screen appears:
The predefined list of message is:
 Abnormal vibration
 Abnormal temperature
 Abnormal noise
 Over greased
 Lubrication needed
 Electrical defect
 Fixation defect
 Belt wear
 Coupling wear
 Oil level
 Defective operation
 Leakage
 Air leak
 Steam leak
 Vacuum leak.
Use the Up or Down arrows to highlight the appropriate message text and then press Enter Key.
You have the possibility to add several messages to a Measurement.
The messages are transferred in Ultranalysis as events.
15.2.5 Setting up the SDT270
The following measurement screen appears, if the right sensor is connected:
15.2.5.1 Adjust Amplification (US sensors)
Using the Up and Down arrows, adjust the amplification until the up and down adjustment amplification indicators
disappear. This one could be set between 0 to 90 dB.
