Technical Data

Type 024.16.720

7. TECHNICAL DATA

7.1. Operating Conditions

WARNING!

Solarradiationandtemperatureuctuationsmaycausemalfunctionsorleaks.

If the device is used outdoors, do not expose it unprotected to the weather conditions.•

Ensure that the permitted ambient temperature does not exceed the maximum value or drop below the •

minimum value.

Ambient temperature 0 ... +60 °C

Protection class: IP65 / IP67 according to EN 60529

(only if cables, plugs and sockets have been connected correctly

and in compliance with the exhaust air concept in chapter “10.3.

Pneumatic connection of the positioner“)

7.2. Conformity

CE mark conforms to EMC Directive 2004/108/EC

(only if cables, plugs and sockets connected correctly).

7.3. Mechanical data

Dimensions See data sheet

Body material exterior: PPS, PC, VA,

interior: PA 6; ABS

Sealing material EPDM / (NBR)

Stroke range of valve spindle: 3 ... 45 mm
