Technical Data
Type 024.16.720
7.6. Electrical Data
7.6.1. Electrical data without bus control 24 V DC
Connections        CableglandM16x1.5,wrenchsize22(clampingarea5–10mm)
withscrew-typeterminalsforcablecross-sections0.14–1.5mm²
Circular plug-in connector (M12 x 1, 8-pole)
Control valve
Power supply 24 V DC ± 10% - max. residual ripple 10 %
Power input ≤ 3.5 W
Input resistance
for set-point value signal 180 Ω at 0/4 - 20 mA / 12 bit resolution
Protection class 3 in accordance with VDE 0580
Analogue position feedback
max. load
forcurrentoutput0/4–20mA   560Ω
Binaryinput        notgalvanicallyisolated0–5V=log“0”,12-30V=log“1”
inverted input in reverse order
Communications interface RS232 Direct connection to PC via RS232 adapter with integrated interface
driver, communication with communications software based on FDT/
DTM technology, see “Table 32: Accessories”.
7.6.2. Electrical data with AS interface bus control
Connections Circular plug-in connector (M12 x 1, 4-pole)
Electricalpowersupply     29.5V–31.6VDC(accordingtospecication)
Deviceswithoutexternalpowersupply:
Max. power consumption 150 mA
Deviceswithexternalpowersupply:
External power supply 24 V ± 10 %
The power supply unit must
include a secure disconnection in
accordance with IEC 364-4-41
(PELV or SELV)
Max. power consumption 100 mA
Max. power consumption
from AS interface 50 mA
