Operation and function
Type 024.16.720
14.2. AuxiliaryFunctions
Thefollowingadditionalfunctionscanbeconguredandparameterizedviathecommunicationssoftware:
Function Description
DIR.ACTUATOR
Assignment of the aeration status of the actuator chamber to the actual position
SPLITRANGE
Signal split range; input signal as a % for which the valve runs through the entire
stroke range.
X.LIMIT
Limit the mechanical stroke range
X.TIME
Limit the control speed
X.CONTROL
Parameterize the position controller
SAFE POSITION
Input the safety position
SIGNAL ERROR
Congurationofsignallevelfaultdetection
BINARY INPUT
Activation of the binary input
OUTPUT
Congurationoftheoutputs(onlywithauxiliaryboardforanaloguefeedback
signal or binary outputs)
Table 30: Auxiliary Functions
The operating instructions for the communications software describe in detail the individual func-
tions,aswellasparameterizationandconguration.
These instructions can be found on the Internet at www.sed-owcontrol.com
