AS interface installation
Type 024.16.720
12. AS INTERFACE INSTALLATION
12.1. AS Interface Connection
ASinterface(ActuatorSensorInterface)isaeldbussystemwhichisusedprimarilyfornetworkingbinary
sensors and actuators (slaves) with a higher-level control (master).
Bus line
Unshielded two-wire line (AS interface line as AS interface cable harness) along which both information (data)
and energy (power supply for the actuators and sensors) are transmitted.
Network topology
Freely selectable within wide limits, i.e. star, tree and line networks are possible. Further details are described
intheASinterfacespecication(A/Bslavemodelconformstotheversion3.0specication).
12.2. Technical Data for AS Interface PCBs
Supply: via AS interface
Outputs: 16 bit set-point value
Certication:Certicateno.87301afterversion3.0
12.3. Programming Data
I/Oconguration 7 hex
ID code 3hex(seebelowforbitconguration)
Extended ID code 1 F hex
Extended ID code 2 4 hex
Prole S-7.3.4
Table 20:
Bitconguration
D1–D16: Valuerangeoftheanalogset-pointvaluefrom0–10.000(0→ 0 %, 10.000 → 100 %)
Parameter bit P3 P2 P1 P0
Output not used not used not used not used
Table 21: Bit conguration
