40
Electrical Installation 24 V DC
Type 024.16.720
11. ELECTRICAL INSTALLATION 24 V DC
11.1. Safety instructions
DANGER!
Risk of electric shock!
Before reaching into the system, switch off the power supply and secure to prevent reactivation!•
Observe applicable accident prevention and safety regulations for electrical equipment!•
WARNING!
Risk of injury from improper installation!
Installation may be carried out by authorized technicians only and with the appropriate tools!•
Risk of injury from unintentional activation of the system and an uncontrolled restart!
Secure system from unintentional activation.•
Following installation, ensure a controlled restart.•
Two kinds of connections are used for the electrical bonding of the positioner:
•Cablegland
with cable gland M16 x 1.5 and screw-type terminals
•Multi-pole
with circular plug-in connector M12 x 1, 8-pole
