8
Part names
4
Part names
4
Table 4 Main dimensions
Dimension
Cabinet 820 mm(W) x 827 mm(D) x 1,800 mm(H)
Complete cabinet 820 mm(W) x 827 mm(D) x 2,100 mm(H)
Figure 4a
Figure 4b
Lindburg.indb 8 2/16/2007 19:12:01
