Sega Lindbergh Universal - Coin insertion test

26
Coin selector
10
Coin insertion test
Perform the check below once a month, at the same time as the coin switch test.
□
Did the coin meter count the coin normally?
□
Did the coin fall into the cash box normally?
□
If the coin was inserted with the return button pressed, did it drop out of the coin return slot?
Figure 10d
Coins inserted here
Coins rejected here
Coins counted here
