Coin selector
25
10
Cleaning the coin selector
● Moisten a soft cloth with water or diluted neutral cleaner, and wring
it out rmly before using it for cleaning.
● Never use machine oil etc. on the coin selector.
● After cleaning the coin selector, insert a standard coin under
normal usage conditions and check that the selector works
normally.
Clean the coin selector every three months. Follow the procedure below to clean it.
1
Turn off the game power supply. Open the entry lid.
2
Remove the coin selector from inside.
3
Open the gate and use a soft brush to brush dirt out.
4
Moisten a soft cloth with water or diluted neutral cleaner, and wring it out rmly before using it for wiping.
5
Remove the cradle.
When removing the retaining ring (E ring), take care not to bend the shaft.
6
Use a soft cloth etc. to wipe dirt off the shaft and bearing.
7
After wiping, blow air onto the coin selector to dry it completely.
To Next Page
