Replacing the game board
13
3
Remove the one thumb screw that fastens the base, then remove it from the cabinet, with the game board still
attached.
Figure 13.1b
4
Remove the four screws and take the game board off.
Screw x 4
M4 x 16, with flat and spring washer
Figure 13.1c
Base
Thumb screw x 1
M4 x 25, using flat and spring washer
