• Use the power supply equipped with an earth leakage breaker. Use of power
supply without such a breaker could result in re if there is a current leakage.
• Have available a securely grounded indoor ground terminal. Without proper
grounding, customers could be electrocuted and product operations might
not always be stable.
• Do not expose the power cord or ground wire. If these are exposed, customers
could stumble over them and easily damage them. Additionally, if these lines
are damaged, there could be a risk of electrical shock or short circuit. Set
these lines at locations where they will not interfere with customer trafc, or
attach covers to them.
• After laying out the power cord on the oor, be sure to always protect it. If the
power cord is left exposed, it can easily be damaged, resulting in electric
shock.
1
Conrm that the main switch is at OFF.
Mains Switch shown in
OFF position
Mains ON/OFF Switch
IEC Inlet
6-3 POWER SUPPLY AND OTHER CONNECTIONS
USE ONLY 250V FUSES
To Next Page
