9-6 JVS TEST
The JVS TEST screen displays information on the connected JVS I/O boards.
Select INPUT TEST to display input data for the currently displayed JVS I/O board.
Select NODE to display information on the next NODE.
If no JVS I/O boards are connected, the message “NO JVS NODE” will be displayed.
■ JVS TEST Screen
NOTE: The screen display will vary depending on the I/O board that is connected.
The gure above is one example.
JVS TEST
INPUT TEST
NODE 1/*
-> EXIT
NAME SEGA ENTERPRISES,LTD.:
I/O BD JVS :837-13551:
Ver1.00
CMD VER 1.1
JVS VER 2.0
COM VER 1.0
SWITCH 2 PLAYER(S) 13 BIT[S]
COIN 2 SLOT(S)
ANALOG 8 CH
ROTARY 0 CH
KEYCODE 0
SCREEN X:0 Y:0 CH:0
GENERAL IN 0 BIT(S)
CARD 0 SLOT(S)
HOPPER OUT 0 CH
DRIVER OUT 6 CH
ANALOG OUT 0 CH
CHARACTER CHARA:0 LINE:0
BACKUP 0
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
To Next Page
