The following information is displayed on this screen.
Move the cursor to EXIT and press the TEST Button to return to the SYSTEM TEST MODE screen.
NODE
The currently displayed JVS I/O board number and the total number of connected
JVS I/O boards
NAME Name of the connected I/O board, etc.
CMD VER Command format version
JVS VER JVS standard version
COM VER Communication version
SWITCH Number of players and number of 1P switches
COIN Number of coin slots
ANALOG Number of analog channels
ROTARY Number of rotary encoders
KEYCODE Keycode input active/inactive
SCREEN Screen position input (X axis, Y axis, number of channels)
GENERAL IN Number of standard switches
CARD Number of card slots
HOPPER OUT Number of hoppers
DRIVER OUT Number of standard output drivers
ANALOG OUT Number of analog output channels
CHARACTER Number of characters/lines displayed
BACKUP Backup present/absent
To Next Page
