70
CONTROL UNIT
10
1
Refer to 10-1 “REMOVING THE CONTROL UNIT ”and take o the control unit.
2
Remove the 2 screws and take o the lens cap.
LENS CAP
SCREW (2)
M3 x 12, w/at & spring washers
3
Remove the 7 screws and take o the scope body L.
SCREW (7)
M3 x 12, w/at & spring washers
SCOPE BODY L
10-3 REMOVING THE SCOPE
