9-11 NETWORK TEST
Use NETWORK SETTING to determine network settings or to test the network.
There is no need to alter these settings for a game that does not use a network.
■NETWORKSETTING(SettingMenu)Screen
MAIN NETWORK Performs a network setting.
NETWORK TEST Performs a network test.
Move the cursor to EXIT and press the TEST Button to return to the SYSTEM TEST MODE screen.
The following information is displayed on this screen.
NETWORK SETTING
MAIN NETWORK
NETWORK TEST
-> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
When using a hub for connecting a number of cabinets in a network, please
change the IP addresses accordingly.
IP (192.168.88.XX) XX indicating the cabinet number. i.e. 192.168.88.01 for
cabinet 1. 192.168.88.02 for cabinet 2 and so on up to a
total of 8 cabinets.
• Do not connect any other device into the same hub as the linked cabinet.
Doing so will cause networking problems between cabinets.
To Next Page
