93
MAINTENANCE,STORAGE AND TRANSPORTATION
LUBRICATING OIL
Check and lubricate all components at the intervals listed in the
periodic maintenance chart. Items not listed in the chart should
be lubricated in the general lubrication interval. The rocker
arm is lubricated at the factory and does not require additional
lubrication. However, if these components are heavily used, the
user may perform additional lubrication as required.
Project
Recommended
model
Capacity
Inspection
procedure
Engine oil
SAE 10W-40 SJ
or higher
2.2 L
Maintain level
in safe range on
dipstick
Front axle
gear oil
SAE 80W-90
GL-5
170 mL
Drive each
2000km(1200MI)
Kilometers.
Rear axle
gear oil
SAE 80W-90
GL-5
260mL
Coolant 3000 mL
Maintain the level
between the fill
lines.
Brake fluid DOT4
Maintain the level
between the fill
lines.
Suspension,
balance bar
grease
——
Grease nozzle
( 3 Pump max) per
500 mile.
