134
MAINTENANCE,STORAGE AND TRANSPORTATION
3. Turn up the positive and negative protective rubber sleeves.
4. Remove the battery negative screw and nut and disconnect
the black (negative) battery cable.
5. Remove battery positive screw and nut and disconnect red
(positive) battery cable.
6. Remove the battery from the ATV.
BATTERY INSTALLATION
NOTICE
To reduce the chance of sparks: Whenever removing the battery,
disconnect the black (negative) cable first. When reinstalling the
battery, install the black (negative) cable last.
1. Clean the battery cables and terminals with a stiff wire brush.
Corrosion can be removed with a solution of one cup of water
and one tablespoon of baking soda. Rinse well with clean
water and dry thoroughly.
2. Place the battery in the tray.
3. Connect and tighten the red (positive) cable and replace the
insulating rubber boot.
4. Connect and tighten the black (negative) cable and replace
the insulating rubber boot.
5. Install the battery pressure plate.
6. Tighten the battery pressure plate bolts.
Verify that the cables are routed correctly.
