109
MAINTENANCE,STORAGE AND TRANSPORTATION
AIR FILTER
The air filter element of the vehicle is a paper air filter element,
and the vehicle needs to be cleaned or replaced after a period of
use, as shown in the periodic maintenance table.
First remove the filter element to check, if the filter is soaked with
oil or serious ash, this situation should not be cleaned, should be
directly replaced with a new filter element.
If there is no oil immersion or serious ash, you can put the intake
side down, lightly knock on the ground, most of the dust can fall
off after vibration, if there is an air pump, you can use the air pump
from the filter side to blow out (not from the intake side to blow
in), blow the dust off, blow clean.
Remove the air filter cover
1
2
3
4
1
Air filter cover
2
Air box cover clamp
3
The filter element
4
Air filter plug
The air filter is located under the air filter cover in front of the
cushion, and the replacement steps are as follows:
