140
MAINTENANCE,STORAGE AND TRANSPORTATION
No. Fuse/Relay Power No. Fuse/Relay Power
F3 IGNITION LOCK 15A R1
REMOTE POWER-ON RELAY
12V 20A
F4 HEAD LIGHTS 20A R2
AUXILIARY STARTER RELAY
12V 20A
F5
DASHBOARD/
ECU/OBD/TBOX
15A R3 IG1 RELAY 12V 20A
F6 FUEL PUMP 15A R4 MAIN RELAY 12V 20A
F13 12V-IG 15A R6
DAYTIME RUNNING LIGHT
RELAY
12V 20A
F14
LIGHT/RAKE/2-4
DRIVE SWITCH
15A R7 FUEL PUMP RELAY 12V 20A
F15 ECU-IG 5A R8 FAN RELAY 12V 20A
F16
ON-METER/BOX/
VEHICLE SPEED
10A R10 HIGH LIGHT RELAY 12V 20A
F17 EPS-IG 5A R11 LOW LIGHT RELAY 12V 20A
F18 POSITION LIGHT 7.5A R12 BRAKE LAMP T RELAY 12V 20A
F20 MAIN FUSE 50A R14 2WD 4WD RELAY 12V 20A
F23 ECU FUSE 15A R15 4WD LOCK RELAY 12V 20A
F24 EPS FUSE 40A
F31 FAN 20A
NOTICE
Due to the continuous upgrading of products, the fuse may have slight
changes. All functional positions and specifications in the fuse box are
subject to the actual product.
