10U
12
3.2 10U for Schuberth C3/C3 Pro Installation Guide
DC Power Charging &
Firmware Upgrade Port
Status LED
Speakers
Antenna
Main Unit
Microphone
Headset Buttons
6. Insert the headset buttons and microphone unit between the external
shell and the left inner shell. Align its snap holder with the front left
snap.
Shoei GT-Air Shoei Neotec
7. Hide the wires behind the center pad and reinstall the cheek pads.
Make sure to click the snaps through the snap holders.
Note:
If you prefer having a foam layer between your ear and the speaker, you can
replace the speaker snap holders with foam speaker snap holders included in
the package. Gently take out the snap holder from the speaker. Place the foam
speaker snap holder on the speaker and gently push it until you hear a click.
Do this for both left and right speakers.
