OmniHub CMP201– User Manual
Page 37 of 103
Table below presents supported channel plans.
Channel Plan
Frequency of RF Channels
Off-Air CH2 57MHz, CH3 63MHz, CH4 69MHz~CH67 791MHz, CH68797MHz,
CH69 803MHz
STD CH2 57MHz, CH363MHz, CH4 69MHz~ CH133 849MHz, CH134855MHz,
CH135 861MHz
IRC CH2 57MHz, CH3 63MHz, CH4 69MHz ~ CH133 849MHz, CH134,
855MHz, CH135 861MHz
HRC CH2 55.75MHz, CH3 61.75MHz, CH4 67.75MHz~ CH133847.75MHz,
CH134 853.75MHz, CH135 859.75MHz
