OmniHub CMP201– User Manual
Page 47 of 103
3.3.7.4 OSD Settings (only available in the CE2-HDMI-R01 module)
You should choose channel first before you set OSD.
• LOGO setting: you can upload several pictures at the same time, and pick one to show
on the screen, when you click the one you want to show that picture field will turn to green.
LOGO Parameter
Range
LOGO Parameter
Range
Position X
0~1920 (Dual)
Position Y
0~1080 (Dual)
Size width
0~1920 (Dual)
Size Height
0~1080 (Dual)
