OmniHub CMP201– User Manual
Page 99 of 103
Bitrate Control CBR
Video Bitrate 1000 ~ 18,000Kbps
GOP Structure IBBP, IPPP, IBP
GOP Size 6~63
Audio MPEG-1 Layer II, AAC , AC3 . Support AC3
pass-through and dual encoding
Audio Mode Stereo (2.0, including downmix)
Audio Sampling Rate 48KHz
HEVC HDMI Encoder (8-CH)
Input 8 channels via 8 HDMI female connectors
(HDMI 1.4)
Video H.264 / AVC MP/HP@L4.2
H.265 / HEVC MP@L4.1
Resolution HD: 1080p-29.97 / 30 / 50 / 59.94 / 60
1080i-29.97 / 30 / 50 / 59.94 / 60
720p-50 /59.94 / 60
SD: 576i-50
576p-50
460i-59.84 / 60
460p-59.84 / 60
*Output supports progressive only, and
resolution support up to 1080p30
Bitrate Control CBR
Video Bitrate 600 ~ 20,000Kbps
GOP Structure IPPP
GOP Size 1~60
Aspect Ratio Automatic or Manual
Audio MPEG-1 Layer II, AAC, AC3
Audio Bitrate 32~192Kbps
Audio Mode Stereo 2.0
Audio Sampling Rate 48KHz
Audio Volume Leveling -20dB~20dB
OSD overlay Text, Image, QR Code
HEVC HDMI Encoder (4-CH)
