OmniHub CMP203– User Manual
Page 107 of 109
Video H.264/AVC SD: MP/HP@L3
MPEG-2 SD: MP@ML
Resolution SD: 576i50, 480i59.94
Bitrate Control CBR
Video Bitrate 1000 ~ 6,000Kbps
GOP Structure IBBP, IPPP IBP
GOP Size 6~63
Aspect Ratio Automatic or Manual
Audio MPEG-1 Layer II
Audio Bitrate 32~384Kbps
Audio Mode Stereo (2.0, including downmix)
Audio Sampling Rate 48KHz
Audio Volume Leveling -20dB~20dB
CVBS Encoder (Professional)
Input 16 channels via 4 DB15 connector,
each DB15 for 4 channels
4 x RCA-DB15 adaptor cables come
along with the module.
Video H.264/AVC SD: MP/HP@L3.0/3.1/3.2
Resolution SD: 576i50, 480i59.94
Bitrate Control CBR
Video Bitrate 1000 ~ 8,000Kbps
GOP Structure IPPP
GOP Size 1~99
Aspect Ratio Automatic or Manual
Audio MPEG-1 Layer II
Audio Bitrate 32~384Kbps
Audio Mode Stereo (2.0, including downmix)
Audio Sampling Rate 48KHz
Audio Volume Leveling -20dB~20dB
Function Module Specification
EAS Processing Module
