OmniHub CMP203– User Manual
Page 57 of 109
EAS module settings
3.3.8.5 Service Configuration and System Operation
Service Configuration and System Operation please refer to CR2-DVBC-00 at page 34
to 35.
3.3.9 CE2-HDMI-02C
CE2-HDMI-02C is a 2-channel HDMI or component HD encoder, supports H.264 / MPEG-
2 HD/SD, MPEG1L2, AAC , AC3 audio, support CC subtitle and analog audio input.
3.3.9.1 Module Status
Module Status for HDMI-02C encoder show the Bitrate on each port when HDMI source
is connected. Video resolution of the source video will appear also on the status. Clicking
on the button will display information on the structure of the transport stream.
This will show more detail about the Service in the channel depending on the parameter
you set on the Module Setting.
