OmniHub CMP203– User Manual
Page 43 of 109
3.3.6 CR2-DVBT2CI-00
CR2-DVBT2CI-00 is a 4-channel DVBT/T2 receiving and descrambling module with 1
RF female connector and 2 CI slots. It can receive 4 RF channels signal simultaneously
and support 2 CAM cards descrambling.
3.3.6.1 Module Status
CR2-DVBT2CI-00 status will show if each port has signal by showing GREEN lock
status on each corresponding channel. The page also shows the total bitrate (Mbps)
and Effective bitrate on each port. For more details on the received signal. You can
check the TS analysis and Service List with the same features as other status of CMP
modules. For TS Analysis and Service List Reference, you can check the CR2-DVBC-
00 Status at page 31 to 35.
CAM Max Bit Rate is from 48Mbps to 108Mbps which you can choose in pull-down list.
