OmniHub CMP203– User Manual
Page 44 of 109
3.3.6.2 Module Settings
To input the parameters of the source you want to receive in CR2-DVBT2-00. Click the
Settings and input the Frequency and Bandwidth. The tables below show the range of
Frequency and Bandwidth for the settings parameters.
Frequency (KHz) 48000~862000
Bandwidth (MHz) 6, 7, 8
3.3.6.3 Module Service Configuration
Service Configuration and System Operation please refer to CR2-DVBC-00 module at
page 34 to 35.
In Descrambling Settings there are CAM1, CAM2 and No Descrambling options. Select
the correct CAM to decrypt the service and click Apply to make the change take effect or
Clear Config button in the right side to clear all configurations.
