OmniHub CMP203– User Manual
Page 13 of 109
CE2-SDI-00 2 channel SDI encoder bitrate supports
H.264/MPEG-2 HD/SD, MPEG1L2, AAC
and AC3 audio, and supports CC and
analog audio input.
Modulator Module
Description
CM2-QAMA-R00 16 channel QAM modulator module, Annex
A/C, non-adjacent output, and 1 RF female
port for output
CM2-QAMB-R00 16 channel QAM modulator module, Annex
B, non-adjacent output, and 1 RF female
port for output
CM2-QAMA-R01 4 channel QAM modulator module, Annex
A/C, adjacent output, and 1 RF female port
for output
CM2-QAMA-R01A 8 channel QAM modulation module, Annex
A/C, adjacent output, and 1 RF female port
for output
CM2-QAMB-R01 4 channel QAM modulation module, Annex
B, adjacent output, and 1 RF female port for
output
CM2-QAMB-R01A 8 channel QAM modulation module, Annex
B, adjacent output, and 1 RF female port for
output
CM2-OFDM-R01 4 channel OFDM modulation module,
adjacent output, and 1 RF female port for
output
CM2-OFDM-R01A 8 channel OFDM modulation module,
adjacent output, and 1 RF female port for
output.
CM2-ISDBT-R01 4 channel ISDBT modulation module,
adjacent output, and 1 RF female port for
output.
CM2-ISDBT-R01A 8 channel ISDBT modulation module,
adjacent output, and 1 RF female port for
output
CM2-8VSB-R01 4 channel 8VSB (ATSC) modulation module,
adjacent output, and 1 RF female port for
output
