SP395 SoundPro Audio Integrator Form7492 Operation Manual
102
Computer Interface
The SP395 Audio Integrator communicates to a PC or Mac computer using RS232 serial
communication format through the DB-9 serial connector. It does not pass serial data through the
USB port. A standard straight-through serial cable is used.
SP395 offers a range of capabilities when it is interfaced to a computer and the computer is
loaded with associated software. You can transfer instrument data memories to a computer for
printing, upgrade the unit operating firmware, display the test results of some functions in real
time on a computer screen or, control the SP395 for automated testing. Here is summary of the
SP395’s computer/software automated capabilities.
Interface Software Utility: Transfer test results held in unit memory data to a PC.
Memory functions include the RTA, SPL, FFT, Energy-Time Graph, Amplitude Sweep
and Impedance Sweep tests.
Upgrader Software: Download firmware revisions and upgrade the SP395 operating
firmware.
TerraLink Software: See real time test results on the computer screen for most or all test
functions.
Uploading memories to a Computer
The SP395 can be interfaced to computer software or special applications programs for the
purpose of moving memory data captured by the SP395’s test functions to a PC. Any test
function in which memory data can be captured can be exported. This includes the SPL, RTA,
FFT, Energy-Time Graph, Amplitude Sweep and Impedance Sweep tests. The memory data can
be used by the computer program for analysis, storage, report generation or printing. The data is
in a comma delimited, ASCII format and includes headers that identify the data. Please call
Sencore to inquire about software availability.
