2 The SenTec Digital Monitoring System (SDMS)
SenTec Digital Monitoring System
15 Sensor Connection Port
16 Multipurpose I/O-Port
(Nurse call, analog output)
17 Serial Data Port (RS-232)
18 Network Port (LAN)
19 Gas Bottle Slot
20 Fan
21 Equipotential Terminal Connector
(ground)
22 Fuse Holder
23 AC Power Connector
24 ON/OFF Switch
Figure 2 Rear Panel of the SDM
WARNING: Refer to
section 1.2.1
for warnings related to
connecting/mounting the SDM to accessory equipment.
CAUTION: Ensure to always use the correct type and rating of
live and neutral fuses. Otherwise you risk damage or malfunction
of the SDM.
CAUTION: Ensure that the fan of the SDM is clear of any
obstructions and that the SDM is located in a well-ventilated
dust-free atmosphere. Failure to do so could cause damage or
malfunction of the SDM.
