3 Maintenance/Safety & Functionality Tests
HB-005615-j
24
Slope Test Control Table CO2 – in kPa (after 5% and 30% CO2 calibration)
Pcal = value after calibration with 8% CO2.
Table is only valid for sensor temp. of 42°C.
Patm
Pcal
5_min
5_ideal
5_max
30_min
30_ideal
30_max
80.0
4.46
2.54
2.64
2.81
16.4
17.8
19.2
80.7
4.50
2.56
2.67
2.84
16.6
18.0
19.3
81.3
4.54
2.58
2.69
2.86
16.7
18.1
19.5
82.0
4.58
2.61
2.72
2.89
16.9
18.3
19.7
82.7
4.62
2.63
2.74
2.92
17.0
18.4
19.8
83.3
4.66
2.66
2.77
2.94
17.1
18.6
20.0
84.0
4.71
2.68
2.79
2.97
17.3
18.7
20.2
84.7
4.75
2.71
2.82
3.00
17.4
18.9
20.3
85.3
4.79
2.73
2.84
3.02
17.6
19.0
20.5
86.0
4.83
2.76
2.87
3.05
17.7
19.2
20.6
86.7
4.87
2.78
2.89
3.08
17.9
19.3
20.8
87.3
4.91
2.80
2.92
3.10
18.0
19.5
21.0
88.0
4.95
2.83
2.95
3.13
18.1
19.6
21.1
88.7
4.99
2.85
2.97
3.16
18.3
19.8
21.3
89.3
5.03
2.88
3.00
3.18
18.4
19.9
21.5
90.0
5.07
2.90
3.02
3.21
18.6
20.1
21.6
90.7
5.11
2.93
3.05
3.24
18.7
20.2
21.8
91.3
5.15
2.95
3.07
3.26
18.8
20.4
22.0
92.0
5.19
2.98
3.10
3.29
19.0
20.5
22.1
92.7
5.23
3.00
3.12
3.32
19.1
20.7
22.3
93.3
5.27
3.02
3.15
3.34
19.3
20.8
22.4
94.0
5.31
3.05
3.17
3.37
19.4
21.0
22.6
94.7
5.35
3.07
3.20
3.40
19.5
21.1
22.8
95.3
5.39
3.10
3.22
3.42
19.7
21.3
22.9
96.0
5.43
3.12
3.25
3.45
19.8
21.5
23.1
96.7
5.47
3.15
3.27
3.48
20.0
21.6
23.3
97.3
5.51
3.17
3.30
3.50
20.1
21.8
23.4
98.0
5.55
3.19
3.32
3.53
20.2
21.9
23.6
98.7
5.60
3.22
3.35
3.56
20.4
22.1
23.7
99.3
5.64
3.24
3.38
3.58
20.5
22.2
23.9
100.0
5.68
3.27
3.40
3.61
20.7
22.4
24.1
100.7
5.72
3.29
3.43
3.64
20.8
22.5
24.2
101.3
5.76
3.32
3.45
3.66
20.9
22.7
24.4
102.0
5.80
3.34
3.48
3.69
21.1
22.8
24.6
102.7
5.84
3.37
3.50
3.72
21.2
23.0
24.7
