The following output signals can be programmed by the operator using the Output
Assignments screen:
Output Signals Description
RealTime In either NO or NO
x
mode the concentration’s output will be
a live reading.
NO In NO mode the concentration’s output will be a live
reading. In NO/NO
x
/NO
2
mode the output will be a read and
hold.
NO
2
The calculated concentration’s output will be updated after
each complete cycle in NO/NO
x
/NO
2
mode.
NO
x
In NO
x
mode the output concentration will be a live reading.
In NO/NO
x
/NO
2
mode the output will be a read and hold.
SamplePres Sample pressure (psig).
AirPres Air pressure (psig).
CaseTemp
Analyzer’s internal temperature (°C).
OvenTemp
Oven temperature (°C). (Heated version.)
ConvTemp
Converter temperature (°C).
PumpTemp
Internal pump temperature (°C). (Heated version.)
DiodeTemp
Photodiode temperature (°C).
CellTemp
Sample cell temperature (°C).
DryerTemp
Gas temperature of the rear-mounted chiller (°C). (Versions
with chillers.)
Sample EPC % of voltage supplied to the Sample electronic proportioning
control valve.
AirEPC % of voltage supplied to the Air electronic proportioning
control valve.
