To select the Output Type press Enter to open the highlighted field. Use the
Up/Down arrows to make your selection. Press Enter again to close the
field.
Once the output type has been selected, use the Left/Right arrows to move the
highlight into the % FS column of the output to be checked. Press Enter until the
% FS value reads 0.000. To adjust the zero (Offset), use the Left/Right arrows
to highlight the Offset column and press Enter to open the field. Make a small
adjustment to the Offset value and then press Enter to close the field. Repeat this
procedure as necessary.
To adjust the output to Full scale, use the Left/Right arrows to move the
highlight into the % FS column and press Enter until the % FS column value
reads 100.0.
Then use the Left/Right arrows to highlight the Gain column. Press Enter
to open the field. Make a small adjustment and press Enter again to close the field
and check the output. Repeat this procedure as necessary for other outputs.
When you are finished making all your changes press to save them. You will return
to the Programmable Analogs menu.
NOTE: Failure to save your adjustments will result in the numbers reverting back to
the defaults after power is turned off and back on.
