Servomex SERVOPRO - Page 126

SERVOPRO NOx Analyzers Page
125
The following table includes typical Programmable Analog Output values:
OUTPUT OFFSET GAIN
0-20 mA 0.000 0.828
4-20 mA 1.658 0.662
0-1 V 0.828 0.828
0-5 V 0.828 0.828
0-10 V 0.828 0.828
PROGRAMMABLE DIGITALS
→ → → →
The Programmable Digitals menu is accessed by pressing from the Output Settings
menu.
NOTE: The Programmable Digitals menu provides access to the analyzer’s digital
outputs for viewing and changing Output Assignments, holding or clearing alarms, and
testing the outputs.
