Electrical interface
Local switchboard
10.3 Electrical interface
10.4 Technical data
64770AXX
12
34567891011
TIP
The terminal connections on the local switchboard are the same as those on the
MOVITRAC
®
LTE-B / MOVITRAC
®
LTP unit. Refer to the operating instructions for
further information.
Conformity IP00, UL90V-0
Environmental –10 – +50 °C
Dimensions [mm] 56 × 33 (not pins) × 16
[in] 2.20 × 1.31 (not pins) × 0.64
