Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
33
4
Installing the MOVI-PLC® advanced DHR41B controller
Mounting/Installation Instructions
Connector X36:
Connection Ethernet 1
System bus (RJ45
socket)
X36
Standard Ethernet assignment
Connector X37:
Connection Ethernet 2
(RJ45 socket)
X37
Terminal X32:
System bus CAN 2
(electrically isolated)
(plug-in terminals, color:
YE/BK)
X32:1
X32:2
X32:3
REF_CAN 2
CAN 2H
CAN 2L
Reference potential for system bus CAN 2
System bus CAN 2 high
System bus CAN 2 low
Terminal X33:
System bus CAN 1
(plug-in terminals, color:
YE/BK)
X33:1
X33:2
X33:3
DGND
CAN 1H
CAN 1L
Reference potential for system bus CAN 1
System bus CAN 1 high
System bus CAN 1 low
DIP switch S1 S1
Top
Bottom
Default IP address
Ethernet 2 connection
Reset button T1 T1 Reset
Front view
MOVI-PLC
®
advanced DHR41B
controller
Designation
LED
DIP switches
Terminal
Function
