Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
4
Installing the DH.41B option in MOVITRAC® B/compact controller
Mounting/Installation Instructions
4.8 Installing the DH.41B option in MOVITRAC
®
B/compact controller
4.8.1 Function description of terminals and LEDs
4.8.2 Connection of RS485 interface COM 1 (connector X24)
The connectors X24 and X34:1/3/5 are connected in parallel. You can connect a
DOP11B operator terminal at X24. If X24 is unassigned, you can connect an operator
terminal or a gearmotor with integrated MOVIMOT
®
frequency inveter to X34:1/3/5.
For more information, refer to section 4.4.5.
NOTE
The MOVI-PLC
®
advanced DH.41B controller is installed according to chapter "Mount-
ing options for the MOVI-PLC
®
advanced DH.41B controller". The MOVITRAC
®
B op-
tion slot and the compact controller provide additional connections and operating dis-
plays for the MOVI-PLC
®
advanced DH.41B controller as described below.
Front view
MOVITRAC
®
B/
compact controller
Designation
LED
Terminal
Function
58905AXX
LED H1
H2
System fault
Reserved
Connector X24:
RS485 COM 1
(RJ10 socket)
X24:4
X24:3
X24:2
X24:1
DGND
RS–
RS+
5 V
Reference potential COM 1
Signal RS485–
Signal RS485+
Voltage output DC+5 V
Lateral view
Compact controller
Designation Terminal Function
58906AXX
Connector X26:
CAN 1 and
voltage supply
(plug-in terminal)
X26:1
X24:2
X24:3
X24:4
X26:5
X26:6
X26:7
CAN1H
CAN1L
DGND
Reserved
Reserved
DGND
DC 24 V
System bus CAN 1 high
System bus CAN 1 low
Reference potential control-
ler/CAN1
-
-
Reference potential control-
ler/CAN1
Voltage supply of controller
X2
H1
H2
2345671
X26
