Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
49
4
Installing the DH.41B option in MOVITRAC® B/compact controller
Mounting/Installation Instructions
4.8.3 Connection of system bus CAN 1/power supply (connector X26)
X26:1/2/3 and connector X33 are connected in parallel (see sec. 4.3.3). MOVI-PLC
®
advanced DH.41B in the compact controller is supplied with power via X26:6/7.
The MOVI-PLC
®
advanced DH.41B controller can be supplied with the required voltage
by MOVITRAC
®
B. For this purpose, connect X26:3 (6)/7 with X46:3 (6)/7 or with
X12:9/8. If the MOVI-PLC
®
advanced DHE41B controller is supplied with DC 24 V by
MOVITRAC
®
B, the function of the MOVI-PLC
®
advanced DHE41B controller is main-
tained after disconnection from the voltage supply. This requires an external DC 24 V
supply to X12:8 / 9 of MOVITRAC
®
B.
60302AXX
Figure 9: Installation of MOVI-PLC
®
advanced DHE41B in MOVITRAC
®
B
X45
X46
1
23456HL ⊥
FSC11B
MOVITRAC
®
B
S1
OFF
ON
7
S2
X44
X26
1234567
X24
H1
H2
X12
1
2
3
4
5
6
7
8
24V IO
DC 24V
-
+
9
GND
=
120Ω
X35
X36
X37
2
4
6
1
3
5
X34
DHE41B
1
2
3
1
3
4
2
1
2
3
1
2
3
1
2
3
X32X33
2
4
6
1
3
5
8
10
7
9
X31
T1
S1
L1 L2 L3 L5XM L6 L7 L8 L9L4 L 10
