Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
61
7
General technical data
Technical Data and Dimension Drawings
7 Technical Data and Dimension Drawings
7.1 General technical data
The general technical data listed in the following table apply to:
• The MOVI-PLC
®
advanced DH.41B controller installed in the inverter
• The MOVI-PLC
®
advanced DH.41B/UOH..B compact controller
Interference resistance Complies with EN 61800-3
Ambient temperature Integrated in MOVIDRIVE
®
MDX61B:
• 0 °C ... +60 °C
(Derating at 40 °C ... 60 °C see MOVIDRIVE
®
MDX60B/61B system
manual)
Installed in MOVITRAC
®
B (AC 230 V; AC 400/500 V to 4 kW):
• –10 °C ... +60 °C
(Derating at 40 °C ... 60 °C see MOVITRAC
®
B system manual)
Installed in MOVITRAC
®
B (AC 400/500 V over 4 kW):
• 0 °C ... +60 °C
(Derating at 40 °C ... 60 °C see MOVITRAC
®
B system manual)
Installed in the MOVIAXIS
®
master module:
• 0 °C ... +45 °C
Compact controller:
• –10 °C ... +60 °C
Climate class EN 60721-3-3, class 3K3
Storage temperature –25 °C ... +70 °C
Climate class EN 60721-3-3, class 3K3
Type of cooling Convection cooling
Degree of protection IP20
Operating mode Continuous duty
(see MOVIDRIVE
®
MDX60B/61B, MOVITRAC
®
B, MOVIAXIS
®
system
manuals)
Pollution class 2 according to IEC 60664-1 (VDE0110-1)
Installation altitude max. 4000 m (asl)
P
i
f
kVA
Hz
n
